Clear Top Party Tent

The roof beams of the Clear Top Party Tent are combined by several split aluminum alloy beams and in a polygon shape, so it is also name polygon top clear tent.

Send Inquiry

Description

The Clear Top Party Tent clear span of polygon top is 10m, 12m, 15m, 18m, 20m, 25m, 30m, 40m, and 50m. The standard side height of 10-40m span width tents is 4m and 5m for 50m and 60m. Bay distance is 5m, the length can be increased and decreased by 5m bay without limit. It can also be customized for clients’ special requirements.

The design for Clear Top Party Tent is with the advanced idea and the structure is quite firm. It is designed for meeting the requirements of bigger interior space and elegant polygonal appearance. The features of polygon top clear tent: modular system, easy to be assembled and dismantled, durable, wind resistance can reach 100-120km/hour, flame retardant with relevant certificates. It is suitable for large-scale concerts, exhibitions, big parties, sports events and so on.

SPECIFICATION:

Span Width	Eave Height	Ridge Height	Bay Distance	Main Profile
10M	4M	7.16M	5M	204X120X4MM
12M	4M	7.4M	5M	204X120X4MM
15M	4M	8.75M	5M	204X120X4MM
18M	4M	9.15M	5M	204X120X4MM
20M	4M	9.42M	5M	204X120X4MM
25M	4M	11.72M	5M	256X121X5MM
30M	4M	13.2M	5M	256X121X5MM
40M	4M	15.4M	5M	300X120X5MM
50M	4M	16M	5M	300X120X5MM
60M	4M	17M	5M	400X120X7MM
